Product Details:
|
| Product Name: | Shut-off Valve | Application: | Radiator Heating Systems |
|---|---|---|---|
| Material: | Brass | Color: | Nickel Plated |
| Size: | 1/2" | Valve Type: | Shut-off |
| High Light: | radiator shut off valve,angled towel radiator valves,angled thermostatic radiator valves |
||
Product Description
1/2" Angled Shut-off Radiator Valve DN15-BC
For use with hydronic runtal radiators and towel warmers, allow you to easily halt the flow of water to your radiator for maintenance and repair.
Nickel plated brass body
Used in applications where your pipe extends from the installation wall.
Hot and cold water in heating and cooling systems.
Technical Specifications
| Model number | DN15-BC |
| Size | 1/2" |
| Maximum static pressure | 10bar |
| Maximum differential pressure | 1 bar |
| Temperature resistance | 5-100°C |
| Kvs | 1.63 |
More types of thermostatic radiator valves
| Model |
Size | Description | Maximum static pressure | Maximum differential pressure | Temperature resistance | Kvs | Remark |
| DN15-A2 | 1/2" | Angle | 10bar | 1bar | 5-100°C | 1.3 | |
| DN15-B2 | 1/2" | Straight | 10bar | 1bar | 5-100°C | 1.5 | |
| DN15-A3 | 1/2" | Straight | 10bar | 1bar | 5-100°C | 0.9 | UK market |
| DN15-B3 | 1/2" | Angle | 10bar | 1bar | 5-100°C | 2.0 | UK market |
| DN15-B4 | 1/2" | Angle | 10bar | 1bar | 5-100°C | 1.5 | |
| DN15-AC | 1/2" | Lockshield | 10bar | 1bar | 5-100°C | 1.7 | |
| DN15-BC2 | 1/2" | Lockshield | 10bar | 1bar | 5-100°C | 1.7 | |
| DN15-BC3 | 1/2" | Lockshield | 10bar | 1bar | 5-100°C | 1.63 | |
| DN15-A3 | 1/2" | Straight | 10bar | 1bar | 5-100°C | 0.9 | chrome |
| DN15-BC | 1/2" | Lockshield | 10bar | 1bar | 5-100°C | 1.63 | chrome, UK market |
| DN15-AC2 | 1/2" | Lockshield | 10bar | 1bar | 5-100°C | 1.14 | chrome,UK market |
| DN20-A2 | 3/4" | Straight | 10bar | 1bar | 5-100°C | 2.2 | |
| DN20-B2 | 3/4" | Angle | 10bar | 1bar | 5-100°C | ||
| DN20-AC | 3/4" | Lockshield | 10bar | 1bar | 5-100°C | 2.4 | |
| DN20-BC2 | 3/4" | Lockshield | 10bar | 1bar | 5-100°C |
